Composite Spout Pouch Bag

Product Overview

Composite spout pouch is a flexible packaging solution combining multi-layer composite film and plastic spout, widely used for liquid, semi-liquid and paste products. Compared with rigid containers such as bottles and cans, it features lightweight, space-saving storage and transportation, convenient pouring and resealing. The built-in spout allows repeated opening and closing, effectively preventing leakage and contamination. This packaging form balances good barrier performance and flexible usability, meeting modern product packaging demands for safety, cost efficiency and user experience.

Material Structure

It adopts multi-layer co-extruded or laminated composite structure, and materials can be selected according to different product requirements. Common layers include:

- Outer layer: PET / BOPP, offering good printing performance, surface stiffness and scratch resistance.z

- Middle barrier layer: AL foil / VMPET / EVOH, to block oxygen, moisture and light, extend product shelf life.

- Inner sealing layer: PE / CPP, with excellent heat-sealing property, anti-leakage and compatibility with contents.

The spout is usually made of food-grade PP, matched with different cap styles. All raw materials can comply with food contact regulations upon request.

Key Features

1. Excellent barrier property: resist oxygen, moisture and ultraviolet, protect contents and prolong shelf life.

2. Reusable spout & cap design: easy to pour out products, resealable after opening to avoid spillage and waste.

3. Good heat-sealing strength: firm sealing edge, strong anti-leakage performance, suitable for liquid filling.

4. Flexible & light weight: reduce packaging weight and logistics cost; pouches can be stacked flat when empty.

5. High-definition printing support: support gravure printing for vivid brand graphics and text.

6. Safe raw material option: food-grade materials available, no peculiar smell, suitable for food and daily chemical products.

Technical Specifications

- Pouch type: stand-up spout pouch / side spout pouch / corner spout pouch

- Capacity range: 50ml ~ 5L

- Film thickness: 80μm ~ 220μm

- Spout size: common 8mm, 10mm, 12mm, 16mm, 20mm etc.

- Printing: up to 9 colors gravure printing

- Heat seal temperature range: 140℃ ~ 180℃

- Working temperature: -20℃ ~ 80℃ (depends on material structure)

- Test standard: can perform leakage test, drop test, oxygen transmission rate & water vapor transmission rate test.

Applications

Suitable for packing various liquid, paste and semi-fluid products:

- Food industry: fruit puree, juice, sauce, honey, edible oil, condiments, beverage concentrates.

- Daily chemicals: laundry detergent, hand wash, shampoo, shower gel, skincare lotion.

- Industrial & chemical: liquid detergent, lubricant, pesticide, coating slurry.

- Other fields: pet liquid food, medical liquid (material to be selected accordingly).

Customization and Services

1. Custom dimension & capacity: tailor pouch size, shape and spout position according to filling machine and product volume.

2. Material structure customization: adjust barrier layer and inner film to meet shelf life, high temperature sterilization or low temperature storage needs.

3. Printing & surface finish: custom artwork, matte/gloss finish, embossing available.

4. Spout & cap options: different spout diameters, flip cap, screw cap, child-resistant cap optional.

5. Supporting service: provide packaging structure suggestion, sample making, migration report and relevant material certificates.

6. Flexible MOQ: negotiate minimum order quantity based on project situation.
